31" x 3HP spdl southwest ind. dpm cnc vertical mill, tr
31" X 3HP Spdl Southwest Ind. DPM CNC VERTICAL MILL, Tr
31" X Axis 3HP Spindle Southwest Ind. DPM CNC VERTICAL MILL, Trak AGE 3 Axis Cntrl, HandWheels, Bed
TRAK 3-AXIS CNC BED MILL w/HAND WHEELS
MODEL: DPM, S/N: 99-4668, NEW: 1999
TABLE SIZE ........................ 10" x 50"
TABLE TRAVEL (X) .................. 31"
SADDLE TRAVEL (Y) ................. 17"
VERTICAL HEAD TRAVEL (Z) .......... 23.5"
SPINDLE TAPER ..................... #40 NST
SPINDLE NOSE TO TABLE ............. 0-24"
SPINDLE CENTER TO COLUMN FACE ..... 17.3"
HEAD SWIVEL LEFT & RIGHT .......... 90 DEGREES
SPINDLE SPEED RANGE ............... 70 - 4,200 RPM
QUILL FEEDS (3) ................... .002, .004, .006 IPR
MAXIMUM WORKPIECE WEIGHT .......... 1,320 LBS
APPROX DIMENSIONS ................. 68"W x 64"D x 95"H
MACHINE WEIGHT .................... 4,100 LBS
TRAK AGE-3 CONTROL, X,Y & Z CNC CONTROL
THREE-AXIS SIMULTANEOUS INTERPOLATION INCLUDING
RS232 PORT & FLOPPY DISK DRIVE
QUILL DIGITAL READOUT (Z IS HEAD UP & DOWN NOT QUILL)
SQUARE BOX WAYS - HARDENED & GROUND
TRANSITION FREELY FROM 3-AXIS CNC TO MANUAL
PERFECT FOR A TOOLROOM OR PROTO-TYPE WORK
INSPECT UNDER POWER IN OUR NEW JERSEYWAREHOUSE
