MULTI COLLOR NIXIE TUBES ITM2M.
Character thyratron matrix indicator with low-voltage control for two inlets in a glass design with flexible leads, the four-colored is designed for construction of an informational reflecting system of individual and collective application.
Connection diagram of electrodes with leads
Net layout diagram view from above
The Russian letters : K, C, , correspond to following colors: K red; C blue, green, yellow.
Basic electric and light technical parameters
Trigger voltage statistical of the 1st and 2nd nets, B 1.2-10
Trigger voltage impulse of the 1st and 2nd nets, B 1.2-10
Blackout voltage of the 1st and 2nd nets, B 14
Transfer current, (summary) mkA,
Cell brightness, cd/m2 , no less than
Viewing angle, degree, no less than +45
Time of readiness, from no more than 90
Subcathode voltage, genitive, B 250-280
Voltage on the 1st anode (constant or the pulsating amplitude), B 80-90
Voltage on the 2nd anode (constant or the pulsating amplitude), B 135-160
Synchronizing actions period of voltage impulses on the 1st and 2nd nets, while temporary deviation between the impulses no more than 4 mkc, mkc no less than 40
Blackout voltage impulse period on the anodes at residual voltages on the 1st anode no more than 4 B
On the second anode no more than 10 B, mkc 300-400
Technical conditions 0.339.350
