Summit 19" lathe- u-252-9000-a
Summit 19" Lathe- U-252-9000-A
* Distance Between Centers: 60"
* Overall Dimensions: 120" x 42"
* Swings Over Cross Slide: 10 3/4"
* Gap Length in Front of Face Plate w/o Jaws: 10"
* Width of Bed on Slideways: 13 3/8"
* Main Spindle Taper: D1-8 Camlock
* Morse Taper with Reduction Sleeve: No. 5
* Tailstock Sleeve Diameter: 3"
* Tailstock Sleeve Stroke: 8 7/8"
* Tailstock Sleeve Morse Taper: No. 5
* Lead Screw Spindle Diameter: 1 3/8"
* Lead Screw Spindle Thread Pitch: 4 T.P.I.
* Steady Reat Diameter Range (min-max.): 19/32" to 7"
* Aloris Tool Posts and Holders
