Atten ADS1022C 25MHZ digital storage oscilloscope
ATTEN ADS1022C 25MHz Digital Storage Oscilloscope
For sale is an ATTEN ADS1022C Digital Oscilloscope, features dual input channels, up to 500MSa/s real time sample rate, up to 25 MHz bandwidth, and much more to simplify your system design and test. The ADS1022C Digital Oscilloscope provides exceptional waveform viewing and measurements in a compact, lightweight package, ideal for production test, field service, research, design, and education and training applications involving analog/digital circuits test and troubleshooting. (While the pictures show both the ADS1022C and Quakko SFG-2120 Function Generators as signal source, SFG-2120 is not included.) Retails well over $500. Please email us with any questions, our hard-working staff will answer every email in no time!
* 500 MSa/s maximum real-time sample rate, 50 GSa/s maximum equivalent-time sample rate
* Memory Dept: 2Mpts for single channel or 1Mpts per channel for two channels
* Dual channel - channel bandwidth: 25MHz
* Ultra compact design: 305mm x 154mm x 133mm (WxHxD)
* 64K 5.7" TFT full color LCD for bright and vivid waveform display
* Advanced trigger modes: Edge, Video, Pulse Width, Slope, Alternative and Delay Trigger
* PictBridge support for easy printing directly from the scope
* Adjustable bigger sensitivity: Effectively filter noise from bigger signal and avoid false trigger
* 32 parameters auto measure functions
* Math functions:+, -, x, /, FFT, Invert
* Unique digital filter and waveform recorder
* Standard interface: USB Device, USB Host, GPIB
* Channel waveform and FFT waveform displayed on split screen
* Pop-up Menu display for ease of use
* 1x /10x Probes (total 2 probes)
