Xp-9102-8304 johnson controls expansion module for dx
JOHNSON CONTROLS INC XP-9102-8304
2 Analog Outputs and 6 Analog Inputs
Extension Modules (XP-91xx or XT-91xx) are submodules that provide various combinations of analog and binary input/output points. They may be mounted next to the controller on the same DIN rail, or remotely, up to 4,000 feet from the controller. Up to eight submodule combinations can connect to the XT Bus of the controller, providing up to 64 additional I/O points. The XT Bus has the same physical characteristics as the Metasys N2 Bus.
http://cgproducts.johnsoncontrols.com/MET_PDF/635050.PDF
