200 x yellow 5MM 4000MCD flat top led lamp super bright
Peak Wave Length (nm) : 585 ~ 595
Forward Voltage (V) : 1.8 ~ 2.2
Reverse Current (uA) : <=30
Luminous Intensity Typ Iv (mcd) : Average in 4000
Life Rating : 100,000 Hours
Viewing Angle : 180 Degree
Absolute Maximum Ratings (Ta=25? C)
Max Power Dissipation : 80mw
Max Continuous Forward Current : 30mA
Max Peak Forward Current : 75mA
Lead Soldering Temperature : 240? C (<5Sec)
Operating Temperature Range : -25? C ~ +85? C
Preservative Temperature Range : -30? C ~ +100? C
