Circuit breaker marine-rated 200A manual flip-to-trip
200 AMP MARINE-RATED MANUAL RESET CIRCUIT BREAKER WITH SWITCH FUNCTION
SPECIFICATIONS - Single Pole Thermal Type Breakers
Typically used in DC power systems in marine applications (as a main or branch circuit breaker), truck and bus systems, RV systems, add-on protection for accessories, lift gates, etc. This unit is external ignition protected and weatherproof.
Main Breaker Protection Interrupt Rating (5kA@ 12VDC). (Consult factory for higher voltage interrupt ratings.)
40 F ( 40 C) to 185 F (85 C).
40 F ( 40 C) to 260 F (125 C).
Black UL-Rated 94V-0 thermoset plastic body. Cover and lever are UL-Rated 94V-0 thermoplastic.
Standard marking includes amp/volt ratings.
Termination: 5/16-18 threaded studs.
Panel or surface-mount options; 50in-lb (5.6 Nm) max.
A manual reset circuit breaker with On-Off switch capability.
ABYC E-11; CE; SAE J1171 (Ignition Protected).
