Hardinge dsm-a bar & second operation automatic lathe
SPINDLE CONSTRUCTION: HARDINGE SUPER-PRECISION
TWELVE SPINDLE SPEEDS: 250-1000; 300-1200; 450-1700; 650-2600; 900-3500; 1100-4200 RPM
HYDRAULIC SUMP CAPACITY: 5 US GALS
MINIMUM COMPRESSED AIR REQUIREMENT:
MAXIMUM COMPRESSED AIR REQUIREMENT:
COOLANT SUMP CAPACITY: 8 US GALS
DIAMETER OF TURRET HOLES: 5/8"
80-3/4" LR x39-1/2" FB x 66-1/2" H
SUPER-PRECISION PRELOADED BALL BEARING SPINDLE
BALL BEARING AIR-OPERATED POWER COLLET CLOSER
HARDENED AND GROUND INDEPENDENT FRONT CROSS SLIDE
HARDENED AND GROUND INDEPENDENT REAR CROSS SLIDE
SIX POSITION BALL BEARING TURRET WHICH IS HYDRAULIC ACTUATED
DEEP HOLE DRILLING CONTROL FOR TURRET
CONTROL UNIT FOR PROGRAMMING COMPLETE AUTOMATIC CYCLE INCLUDING THE OPENING AND CLOSING OF COLLETS, OPERATION OF THE FRONT SLIDE, REAR SLIDE AND VERTICAL SLIDE, AND ALL SIX STATIONS OF TURRET. MANUAL CONTROL OF POWER CHUCKING IS ALSO PROVIDED.
CONTROL UNIT FOR PRESETTING OF INFINITELY VARIABLE FEEDS OF CROSS SLIDES, VERTICAL SLIDE AND SIX TURRET POSITIONS
AUTOMATIC DRIVE SHAFT SPINDLE BRAKE
