Leviton pin & sleeve 20A 250V 3ø watertight plug 420P9W
Leviton Pin & Sleeve 20A 250V 3 Watertight Plug 420P9W
Leviton 420P9W watertight pin and sleeve plug. Industrial Grade, IEC 309, 3-pole, 4-wire, grounding, rated 20A 250VAC 3-phase. Out-of-box special; includes only what is shown in the photos. Features include:
* Rugged housing, made of superior performance Valox 357, provides maximum corrosion protection and makes the device resistant to impact and abuse; greater resistance to temperature extremes, V-0 flame rated and superior UV stability
* Contact carrier resists arcing and internal heat build-up
* Multiple contact points assure a continuously reliable electrical connection
* Clean brass pin construction resists corrosion, provides superior contact and low electrical resistance
* Pins are designed for manageable insertion/withdrawal force
* Rounded pin tips reduce insertion force and decrease wear on the contact surface area
* Solid brass terminal screws provide maximum clamping pressure
* Locking ring secures plug to connector or receptacle
* Watertight Chloroprene onion skin grommet provides a precise, reliable seal at the cable entry point
* External cord clamp made of tough impact-resistant Valox 357 accomodates a wide variety of cord sizes and protects terminals from strain
* Large diameter combination head terminal screws are aligned on a single plane for easier access
* Internal hinged cord clamp adds strain relief and swings aside when wiring terminals
* Ground, neutral and phase terminals are clearly identified by color coding or letters and numbering on both front & back side
* Rated for both 50 and 60 Hz applications
* Matching 420*9W Pin & Sleeve Devices
