Dayton 3N316 3 phase 3/4 hp motor
Dayton 3N316 3 Phase 3/4 HP Motor
Inverter Duty Motor, Open Drip Proof, HP 3/4, RPM 1140, Voltage 208-230/460, NEMA Frame 56H, 1.25 Service Factor, 60/50 Hz, 74.0 Nominal Efficiency, Rigid Mounting, Double-Shielded Ball Bearings, Thermal Protection None, Full Load Amps 3.2-3.2/1.6, Steel Frame, Insulation Class B, Ambient 40 C, CW/CCW Rotation, Shaft Diameter 5/8 In, Shaft Length 1 7/8 In
* Item Energy Efficient Motor
* Full Load Amps: 3.2-3.2/1.6
* Bearings: Double-Shielded Ball
* Length Less Shaft (In.): 10 1/8
* Efficiency Group: Not Covered
* Rated: 50 Hz Operation on 190/380V at Rated HP and 5/6 of 60 Hz RPM
* Standards: UL Recognized (E47479), CSA Certified
This listing is for a New Dayton 3N316 3 Phase 3/4 HP Motor. See listing images of actual item, condition and included contents.
