Used 21,300 cfm joy manufacturing multiclone
USED 21,300 CFM JOY MANUFACTURING MULTICLONE
MODEL 9VC10, SIZE 50-5 WITH ABRASION RESISTANT TUBES AND VANES. CONSTRUCTED OF 316L STAINLESS STEEL. DESIGNED TO COLLECT AT LEAST 97% BY WEIGHT OF DUST WITH 90% BEING LARGER THAN 10 MICRON IN SIZE. OUTLET CONDITIONS OF 1.54 GR/DSCF AT 2.8" W.C. PRESSURE DROP AT 5000 #/HR INLET DUST LOADING. UNIT BUILT IN 1988. EXCELLENT CONDITION. 316 STAINLESS STEEL HOUSING & TUBE SHEET. TUBES ARE 304 STAINLESS STEEL. DIRTY AIR INLET MEASURES 32" x 110". CLEAN AIR OUTLET MEASURES 62" x 110". 6" DIA. CLEAN AIR VENTURI OUTLETS. OVERALL HEIGHT = 187". 24" MANWAY IN HOPPER. 4" DIA. CLEAN OUT PIPE. 8" DIA. FLANGED OUTLET. DIRTY AIR HOUSING MEASURES 108" x 56" x 50" straight side. HOPPER HEIGHT = 104". NO CLEAN AIR PLENUM AVAILABLE.
