Hid thinline ii proximity card reader 5395CG100-G1021
* Used HID ThinLine II 125 kHz Wall Switch Plate Proximity Card Reader 5395 5395CG100-G1021 Grey
Providing performance and reliability, HID's attractive, unobtrusive ThinLine II proximity card reader is housed in a two-piece, weatherproof secure potted enclosure.
* The size of most standard U.S. switch plates.
* Available with Wiegand or Clock-and-Data interface.
* Potted reader suitable for indoor or outdoor use.
* Base part numbers: 5395 (Wiegand), 5398 (Clock-and-Data).
* 18" (45 cm) wire pigtail standard; consult factory for 9' (2.7 m) pigtail available by special order.
* Easily installed and maintained with the use of replaceable covers.
* Available with a Wiegand or Clock-and-Data interface.
* Provides high reliability, consistent read range and low power consumption.
* Features include multicolor LED and internal control or host control of the LED and beeper.
* Mounts directly on metal with minimal impact on the read range performance.
* Aesthetic design available in two cover designs and four colors to match any d cor.
* Includes multilingual installation manual.
4.70" x 3.00" x 0.68" (11.9 x 7.6 x 1.7 cm)
Linear power supplies are recommended.
Average: 30 mA (5 VDC); 20 mA (12 VDC)
Peak: 110 mA (5 VDC); 115 mA (12 VDC)
-22 to 150 F (-30 to 65 C)
0-95% relative humidity non-condensing
Wiegand interface: 500 feet (150 m)
Clock-and-data interface: 50 feet (15 m)
Recommended cable is ALPHA 1295 (22 AWG) 5 conductor minimum stranded with overall shield or equivalent. Additional conductors may be required for LED or beeper control.
FCC Certification, United States
EU and CB Scheme Electrical Safety (EN60950 and IEC60950 ITE Electrical Safety)
Fifteen EU Countries under the R&TTE Directive (EN300 330 - SRD, and ETS 300 683 - EMC)
