Nsk nakanishi ecomo high torque air grinder EA45-20
Nsk Nakanishi Ecomo High Torque Air Grinder EA45-20
HIGH TORQUE 45 ANGLE TYPE AIR GRINDER EA45-20
For grinding, polishing, engraving of finished parts and mold cavities.
Excellent performance on a wide range of materials such as resins, ceramics, ferrous, non-ferrous, gem stones and wood.
Ergonomically designed for continuous use with maximum confort.
Air Consumption : 3.88~6.00CFM
Proper Air Pressure : 58~87PSI
Air Hose Length : 4.5 ft Weight : 6.00 oz. excluding hose
Max. Tool Mounting Depth is 1.18"
Minimize the overhang of the tool to prevent to bending, breaking and vibration.
Special Lubricate Oil Mechanism "LUBE-RING" installed.
Easy to manually lubricate without air line disconnection.
Reduced weight for prolonged usage.
The special vane motor enables the low air volume usage with high power and RPM.
Easy Operation with the elastomer grip
Deeper chucking area prevents accidental bending or breaking of tools.
"NK Micron Collet" is designed with the same high precision technology as our machine spindle collet, eliminating excessive runout.
Calculated air pressure and motor speed correlation
Appropriate Air Pressure, Air Consumption, Motor Speed
58PSI 3.88CFM 19,000 min-1 (rpm)
73PSI 4.94CFM 20,500 min-1 (rpm)
87PSI 6.00CFM 22,000 min-1 (rpm)
Turn the ON/OFF Ring to set ON/OFF and to adjust motor speed.
ECOMO is packaged in an environ mental friendly box.
