> Oz~jet/asian 14" tilting table saw ctas-14 parts manual
Oz~jet/asian 14" tilting table saw ctas-14 parts manual
14" Tilting Arbor Table Saw CTAS-14
This is a reproduction, not a photocopy, of an original JET CTAS-14 14-inch Tilting Arbor Table Saw Instructions and Parts Manual. This manual contains general safety instructions, operation instructions, assembly instructions, adjustments, maintenance, lubrication, and a complete set of exploded view diagrams of the parts with description. Please read index below.
Saw diameter...............................................350mm (14in)
Dia. of saw arbor..........................................25.4mm (lin)
Max. saw projection....................................1 30mm (5 1/8in)
Table dimension.....................................1220x965mm(48x38in)
Arbor tilting angle..............................................0- 45
Spindle speed...............................................3,750r.p.m.
Power required..............7 1/2Hp (3 phase, 220/440V, pre-wired 220V)
Net weight.............................................400kgs (880 lbs)
Gross weight..........................................500kgs (1100 lbs)
General Safety Precautions............................................1
Additional safety rules for tilting arbor table saws..................2
Unpacking and cleanup.................................................2
Assembling extension wings............................................2
Installation and levelling............................................2
Assembling and aliging motor motor pulley and belt....................3
Assembling blade guard................................................3
Assembling guide rails................................................4
Miter gage operation and adjustment...................................4
Rip fence operation and adjustment....................................4
Adjusting miter gage slots parallel to saw blade......................5
Table insert adjustment...............................................5
Adjusting 90 and 45 degree positive stop..............................5
Changing arbor extensions.............................................6
Parts list.....................................................7,8,9,10
