New 6W microwave terrasat 6-7GHZ power amplifier pa sma
NEW 6W Microwave TERRASAT 6-7GHz Power Amplifier PA SMA
6 Watt TERRASAT 6.40 - 7.10 GHz Power Amplifier SMA
This PA has a gaas mmic input, attenuator and then a 6Ghz filter, a low level gaas mmic, a boxed amplifier ( very small with bonding) a final 6472-6F gaas fet, and an isolator. The output between 6,4 and 7,2 Ghz is about 6 watt's and is still effective at 5.7 Ghz and can output a few watt's.
Connectors: TX IN sma, TX OUT sma
Connection Scheme: red = + 8Vblack = earthwite = - 12 V (negative)brown = + 12VOrange = + 5,5Vyellow = rf detectorgreen = agcblack = earthblue = mute (don't know which voltage)
