Nikon npl-332 5" total station prismless single display


Nikon NPL-332 5" Total Station Prismless Single Display
Includes: Nikon NPL-332, Battery, Charger, Tool, Cover and Case - As Pictured
Nikon total stations deliver speed, accuracy and ease of use and superior Nikon optics
Nikon total stations offer fast, accurate electronic distance measurement (EDM), easy-to-use keypads and legendary Nikon optics to help you work more quickly and productively in the field. You'll see the difference when you look through a Nikon total station. Nikon optics effectively let in more light. You see brighter, sharper images even in the low-visibility conditions typical in the field. Better optics help you aim more precisely, and they're much easier on your eyes something you'll really appreciate on long workdays. And all Nikon telescopes use a unique linear focusing mechanism that improves focusing at both short and long distances.
NPL-332 Reflectorless Total Station - MSRP $7,495.00
NPL models have reflectorless capabilities that expand the environments you can survey without sacrificing speed or accuracy you can survey in areas where using a prism would be impossible or dangerous. NPL models use an eye-safe Class 1 laser to measure points with a (5+2 ppm x D) accuracy. You can also use NPL models with reflector sheets or a standard prism, and independent measurement keys let you switch back and forth between prism and prismless modes with single-button simplicity.
Standard and reflectorless measuring modes
Waterproof construction (IXPx6/IEC 526)
Ergonomic keyboard design with full alphanumeric input
10,000-record data memory with job manager (up to 32 jobs)
Powerful and practical on-board survey programs, including COGO
26x telescope magnification with world-renowned Nikon optics
1" minimum display; 5" accuracy
Ideal for law enforcement and accident investigation
Up to 16 hours of continuous distance and angle measurement with 1 battery (NPL versions: 6.5 hours in reflectorless mode)
Range: up to 650 feet reflectorless; up to 16,400 feet with single prism
Magnification 26x (16x/32x with optional eyepieces)
Effective diameter of objective 40mm/1.57 in. (EDM: 50mm/1.97 in.)
Minimum focusing distance 1.6m/5.3 ft.
(white target)*1 1.6 to 210m (5.3 to 682 ft.)
Range with Nikon specified prisms
Normal conditions (Ordinary haze, visibility approx. 20km/12.5 miles)
(5 x 5cm) 1.6 to 300m (5.3 to 980 ft.)
With mini prism 1.6 to 3,000m (5.3 to 9,840 ft.).
With single prism 1.6 to 5,000m (5.3 to 16,400 ft.).
Good conditions (No haze, visibility of over 40km/25 miles)
Accuracy (Prism/Precise mode) (3+2ppm x D)mm
(3+3ppm x D)mm ( 20 C to 10 C, +40 C to +50 C)
Accuracy (Reflectorless/Precise mode) (5+2ppm x D)mm
(5+3ppm x D)mm ( 20 C to 10 C, +40 C to +50 C)
Precise mode 1.3 sec. (initial 2.0 sec.)
Normal mode 0.5 sec. (initial 1.6 sec.)
Precise mode 1.6 sec. (initial 2.6 sec.)
Normal mode 0.8 sec. (initial 2.0 sec.)
Ambient temperature range 20 C to 50 C/ 4 F to +122 F
Temperature range 40 C to 60 C/ 40 F to +140 F
Barometric pressure 400 to 999mmHg/533 to 1,332hPa/15.8 to 39.3 in.Hg
Reading system Photoelectric detection by incremental encoder
Horizontal angle Single(NPL-332)
(Degree, Gon, MIL6400) Degree: 1/5/10 , Gon: 0.2/1/2mgon, MIL6400: 0.005/0.02/0,05mil
(horizontal and vertical) 5"/1.5mgon(3"/1.0mgon:NPL-362)
Method Liquid-electric detection
Focusing range 0.5m/1.6 ft. to
Display Graphic LCD (128 x 64 dot)
Dimensions (W x D x H) 168 x 173 x 347mm/6.6 x 6.8 x 13.7 in.
Main unit (with battery) 5.3kg/11.7 lbs.(NPL-332)
measurement Approx. 6.5 hours (Reflectorless mode: 7.0 hours)*3
every 30 seconds Approx. 15 hours (Reflectorless mode: 16 hours)
Angle measurement Approx. 27 hours (Prism and Reflectorless modes)
Used Nikon NPL-332 5" Total Station Prismless Single Display, as pictured.
