Metal Bellows Corp. MB-601 High Pressure Vacuum Pump / Compressor
208-230/460 Volts, 60 Hz, 1725 RPM, 5.3-5/2.5 Amps, 3 Phase
Whether they are off-the shelf or specially designed for a particular application, Met Bel pumps share these common features:
* Long Life uniform, symmetrical welds that assure long life
* Stainless Steel all wetted surfaces made from corrosion resistant 300 Series stainless steel except for the valve assembly gaskets which are either Teflon or Viton (all metal surfaces available on request)
* No Maintenance no wearing surfaces and no lubrication required
* Hermetically Sealed hermetically sealed welded bellows that provide positive containment. Every pump is pressure tested to assure leak-tight integrity, with certification to mass spectrometer leak testing available
* Infinite Number of Cycles bellows and valves designed with stress levels below defined endurance limits of materials allowing for an infinite number of cycles
* Sealed Ball Bearings motor and drive assembly containing permanently lubricated and sealed ball bearings
* Positive Bellows Displacement eccentric between the bearings and the motor shaft that provides motion for positive bellows displacement
* Gas analysis, analytical instrumentation Sampling
* Nuclear radiation monitoring
* High voltage electronics cooling and wave guide pressurization
* High temperature engine exhaust analysis
* Radioactive, toxic, costly gas processing
* Research and laboratory experiments providing contaminant free samples
* Commercial aircraft potable water pressurization system
