Carotron Adaptable Drive Package Board Model ADP102 NEW
New Carotron Adaptable Drive Package Model ADP102
The Carotron ADP100 Series Adaptable Drive Package provides full range speed or torque control of shunt wound or permanent magnet D.C. motors. Model ADP102 operates motors between 1/4 and 2 horsepower.
* ADP102 Series operates at 115 or 230 VAC input for 90 or 180 VDC motor armatures.
* Independently adjustable Acceleration and Deceleration, two ranges selectable by programming jumper
* A single "Enable" input for starting and stopping
* A hard firing, high frequency multi-pulse gating circuit
* Inner current loop for fast stable response under varying load conditions
* I.C. regulated power supplies, metal film resistors and cermet potentiometers for stable operation with fluctuations in temperature and line voltage
* .110 quick connect type terminals for test points and optional circuit access
* Plug-in type control board and low profile chassis provide custom design flexibility for OEM applications
* A.C. Input: 115 VAC 10%, 50/60 HZ 2 HZ (ADP102 only), 230 VAC 10%, 50/60 HZ 2 HZ
* Horsepower Range: 1/4 - 1 HP @ 90 VDC 1/2 - 2 HP @ 180 VDC
* Armature Output: 0- 90 VDC @ 11 amps continuous, 0- 180 VDC @ 11 amps continuous
* Field Output: 100 VDC @ 1 amp max. for 115 VAC input, 200 VDC @ 1 amp max. for 230 VAC input
* Torque Regulation: 2% of range selected
* Ambient Temperature: Chassis model: 0 to 55 degrees C, Enclosed model: 0 to 40 degrees C
* Adjustments: Minimum: 0 to 25% of speed (speed mode), 0 to 10% of rated current (torque mode)
* Maximum: -20 to +10% of base speed (speed mode), -20 to +10% of rated current (torque mode) IR
* Compensation: Range set by current range jumper
* Current limit: 0 to 150% of current range
* ACCEL and DECEL: Linear, independently adjustable 2 ranges, 1 - 5 sec. or 4 - 40 sec.
