Verifone omni 3210 credit card terminal no accnt req'd
The VeriFone Omni 3210 is simply remarkable and remarkably simple. Simple to use with a large graphical display, intuitive ATM-style keypad, extra-size menu prompts, and SoftPay software, your help desk. Simple to install with a stylish, which minimize training and reduce calls to compact design that saves space and requires no separate printer or peripherals to clutter the countertop. Simple to own featuring VeriFone s acclaimed reliability, minimal moving parts, and a covered paper path for less downtime and fewer service calls.
Tamper-resistant features protect terminal s inner workings.
Master/Session, DUKPT, and Triple DES key-management schemes safeguard user PINs.
Integrated, high-speed, graphics-capable thermal printer is quick and quiet, producing receipts and reports at up to 12.5 lines per second. Covered paper path minimizes jamming.
Large 8 x 21 (128 x 64 pixels) backlit display is easy to read under various lighting conditions. Graphical support and split-screen capabilities allow text and images to be run side by side.
Triple-track card reader accepts all magnetic-stripe cards, including drivers licenses.
Flash memory supports remote downloading of applications and operating system software.
Two telco ports eliminate the expense of a second phone line.
Two RS-232 ports provide connections for optional peripherals such as a check reader, smart card reader, bar-code wand, or external PIN pad.
Five-year terminal/one-year printer and swivel stand warranty is testimony to the Omni 3210 terminal s reliability, and ensures an outstanding long-term return on investment.
128-Kbyte Flash EPROM and 512-Kbyte battery-backed SRAM standard
Available in optional 128-Kbyte, 256-Kbyte, and 1-Mbyte RAM models
128 x 64 pixel graphical LCD with backlighting
Supports the following configurations:
6 x 8 characters/8 rows x 21 columns
8 x 16 characters/4 rows x 16 columns
16 x 16 characters/4 rows x 8 columns
Triple track (tracks 1, 2, 3), bi-directional
3 x 4 numeric keypad, plus 8 soft function keys and 4 screen-addressable keys
Two telco and two RS-232 ports support peripherals including check readers,
smart card readers, bar-code wands, and external PINpads
Speed: up to 12.5 lines per second
10 international character sets
Paper: 58 mm (2.25 in.) standard roll, single ply
Master/Session, DUKPT, and Triple DES encryption
Bell 103/212A and CCITT V.21/V.22/V.22 bis: 300/1200/2400 bps (asynchronous dial) and 1200/2400 bps (synchronous dial)
Five years on terminal, one year on printer and swivel stand
Height: 75 mm (3.1 in.); width: 146 mm (5.6 in.); depth: 290 mm (12 in.);
weight: 1050 gm (2 lbs., 5 oz.)
USA: input 120 VAC, 60 Hz; output 22 VAC, 2A
International: output 22 VAC, 50-60 Hz; output 25.5 VDC, 1.57A
1 Mbyte RAM; optional: 512 Kbyte
128 x 64 pixel graphical LCD display with backlighting; supports the following configurations: 6 x 8 characters/8 rows x 21 columns; 8 x 16 characters/4 rows x 16 columns; 16 x 16 characters/4 rows x 8 columns
Bi-directional: supports triple track (tracks 1,2,3) Keypad 3 x 4 numeric keypad, plus 8 soft function keys and 4 screenaddressable keys
Two telco ports, one RS-232 port and one PINpad/Barcode port
Clam shell, thermal, 13 lines per second; MTBF: 4 million lines; graphic printing capability; paper: 2.25 in (58mm) standard roll; single ply
Bell 103/212A (300/1200/2400 bps); CCITT V.21/V.22/V.22 bis (300/1200 bps/2400 bps) asynchronous dial modem 2400/1200 bps synchronous dial modem
79 mm (3.1 in.); width: 132 mm (5.3 in.); depth: 260 mm (10.25 in.); weight: 785 gm (1 lb. 11.45 oz.)
0 to 40 C (32 to 104 F) operating temperature, RH 95% maximum
Standard: Input 120 VAC, 60 Hz Output: 22 VAC, 2A Optional: Input 100-240 VAC, 50-60 Hz Output: 24 VDC, 1.5A
