Leviton L20-20 locking receptacle 20A 347/600V 3øy
Leviton L20-20 Locking Receptacle 20A 347/600V 3 Y
Leviton 2460 locking receptacle. Industrial Specification Grade, NEMA L20-20R, 4-pole, 4-wire, non-grounding, rated 20A 347/600V, 3 Phase Y. Each is individually packaged; packaging made differ from photo. Features include:
* Uncompromising industrial-grade quality for superior performance and long service life
* Terminals clearly identified to speed and simplify wiring
* Heavy-duty, impact resistant construction for top performance in the environmental extremes of grueling industrial settings
* One-piece .040" thick brass, high-copper content contacts with nickel-plated contact clamp type terminals
* Contacts deeply seated in thick walled face
* Extra-thick .050" mounting strap
* Triple combo mounting and terminal screws (straight slot, Phillips, and Robertson)
* Molded-in terminal identification letters
* Accepts #8-#14 AWG solid or stranded conductors
* Mechanically-secured all-brass ground path
Click here to see matching L20-20 plugs, connectors & receptacles. This is New Old Stock and is returnable for any reason. (SKU #L2460-065-EA; 0.30 Pounds)
