Ademco 685 receiver


Normal wear and tear from use!
The 685 is truly the ultimate in Central Station Digital Communications. This receiver is so versatile it can make a dramatic difference in the overall central station efficiency the moment you put it to work.
It starts proving its worth by accepting transmissions from virtually any communicator in service, including ADEMCO s VISTA systems with high-speed, 4+2 Express and Contact ID formats. It s compatible with Ademco, Sescoa, Radionics formats, Versus Derived Channel and AlarmNet/ Ademco 900 MHz Long Range Radio formats. The 685 can also accommodate up to eight phone lines, each with built-in line fault monitoring, and process calls on all lines simultaneously.
Accepts transmissions in ADEMCO (low speed/high speed/4+2 express/sensor ID), Sescoa and Radionics formats
Accepts 10, 20, 40 pulse per second and 10 DTMF char/sec data transmissions
Double message or single message check sum verification
Stores up to 113 messages for subsequent display during heavy traffic or "trouble" periods
Display lights for burglary, fire, holdup, restore, test, openings, closings, low battery- triggered by incoming signal
Display lights indicate AC failure, low battery, telephone line fault, printer failure-at receiver
Three or four digit account number
Features built-in connectors for serial printer, parallel printer and modem
Built-in RS232 computer inter-face; total supervision of connection to computer and message transfer using "ACK," "NAK" and interrogation signals.
Built-in battery charger for uninterrupted long-term operation
Displays time and date in either civilian or military modes, and in either U.S. or European style
If a second alarm is received within 10 seconds of original alarm, built-in buzzer will NOT resound after being silenced
Modular design for easy rack and desk mounting, optional cabinet (68SCX) available for desk mounting
Compatible with audio and video alarm verification systems from ADEMCO
Total time between acknowledgement and kiss-off under five seconds with ADEMCO high-speed/express/contact ID formats
Transmissions converted into plain English
Built-in table of 27 messages related to fire, burglary and restore
Built-in test and diagnostics of phone lines
Automatic reporting of phone line failure to host computer and printer
Battery test feature with automatic status reporting.
