Soekris engineering NET4526 sbc with dual minipci RJ45
This compact, low-power, low-cost, advanced communication computer is based on a 100 or 133 Mhz 486 class processor. It has one 10/100 Mbit ethernet ports, up to 128 Mbyte SDRAM main memory and uses a CompactFlash circuit soldered onboard for program and data storage. It can be expanded using up to two MiniPCI type III boards.
It has been optimized for use as wireless router using Mini-PCI wireless boards, but has the flexibility to take on a whole range of different functions as a communication appliance. The board is designed for long life, low power and extended temperature range.
It is available in any volume in two standard stock versions, and as board only or with a small metal box and various power supplies. The board can be customized according to requirements when ordering higher volume.
Please note that the available standard case has cutouts for two RP-TNC Jacks for the external antennas, but does not include the connectors and cables.
Click on the pictures at right for high resolution versions.
Standard stock configurations:
net4526-30: 133 Mhz CPU, 64 Mbyte SDRAM, 1 Ethernet, 1 Serial, 256 Mbyte CF Flash, 2 Mini-PCI sockets, PoE.
* 16-128 Mbyte SDRAM, soldered on board
* Soldered CompactFLASH, 16 Mbyte to 128 Mbyte.
* 1 10/100 Mbit Ethernet ports, RJ-45
* Power LED, Activity LED, Error LED
* 1-2 Mini-PCI type III sockets
* 5 bit general purpose I/O, 8 pins header
* Hardware watchdog and temperature sensor
* Power using external power supply is 11-56V DC, max 10 Watt
* Supports Power over Ethernet according to the 802.3af standard
* Operating temperature 0-60 C, typical -30 to 60 C
