Lightmaster ii lm-1000 outdoor lighting photo control
LightMaster II LM-1000 Outdoor Lighting Photo Control
LightMaster II LM-1000 with Installation/Operating Instructions
Manufactured byt Area Lighting Research Inc.
The Lightmaster II turns lights on at dusk. then turns them off later in the evening when no longer needed. If desired, it will also turn them on again before dawn. Settings on the control's base allow the user to select the specific Evening-Off and Predawn-On times.
Lightmaster II also advances 1-hour for day-light-savings time and resets itself after power outages. Applications include billboards, landscape lighting parking lots, sports, and recreational areas.
Fail Mode: On (Contacts normally closed)
Power Consumption: 1.5 Watts (avg) @ 120 volts
Switch Lifetime: Exceeds 5,000 on/off operations
Temperature Range: -40 C to +65 C @ 96% RH
Cover Window: High impact polypropylene with UV resistant Acrylic
Base: High-temperature polyester (PBT)
Gasket: Cross-linked polyethylene
Connection: 3-pole locking-type, with solid brass legs
Light Sensor: Non-drifting phototransistor
Built-in Daylight Savings Time Adjustment
Resets Automatically After Power Outages
360 Joule MOV Surge Protection
Rain-tight / Dust-tight Housing
