9.75" swg 20" cc karsten 16SA od grinder, hyd tbl, auto
9.75" Swg 20" cc Karsten 16SA OD GRINDER, HYD Tbl, AUTO
9.75" Swing 20" Centers Karsten 16SA OD GRINDER, HYD TABLE, AUTO INFEED, SWING AROUND I.D.
9.750" X 20" KARSTENS "MADE IN GERMAN" HIGH PRECISION
TABLES SWIVELS, CCW 13- 1/2 DEG.
GRINDING WHEEL: 14" DIAMETER X 2"W MAX.
COARSE ADJUSTMENT OF UPPER WHEEL SLIDE IS MADE EASY BY DOVETAIL AND CLAMP
AUTOMATIC INFEED: LEFT PICKFEED
SELECTION OF PLUNGE, CONTINUOUS INFEED RATE USING RATCHET
& PAWL. FEED RATE IS CONTROLLED ELECTRONICALLY BY
FREQUENCY (THERE IS NO SPARK OUT TIMER)
HANDWHEEL FOR INFEED 1 REV. : .010" EACH CAL. .0005"
VARIABLE SPEED: 60 RPM TO 540 RPM
APPROX. DIMENSIONS: 66"L-R X 48"W X 52"H
AUTOCYCLE (STARTED WITH SINGLE LEVER)
ADAPTOR w/FACE PLATE FOR MOUNTING A CHUCK
SET UP FOR COOLANT WITH GUARDS, SPIGOT ABOVE THE GRINDING
WHEEL, BUT THE MACHINE DOES NOT HAVE THE COOLANT TANK,
PUMP, HOSES & PLUG TO INTERFACE WITH THE MACHINE
BRACKET BEHIND THE O.D. WHEEL FOR INTERNAL GRINDING,
WIRED PRESENTLY FOR 220 VOLTS, 3 PHASE, 25 AMP FULL LOAD
