Tektronix 466 storage oscilloscope for parts or repair
Min. Vertical Sensitivity: 5 mV/div
Maximum Vertical Sensitivity: 5 V/div
Vertical(or Deflection Factor) Accuracy: 3 %
Maximum Input Voltage: 250 V(dc+p
Main time base - lowest: 50 ns/div
Main time base - highest: .5 s/div
B Sweep Time Base (low): 50 ns/div
B Sweep Time Base (high): 50 ms/div
Time base Magnification factor (X?): x10
Trigger Source External,Internal
Trace writing speed (Analog Oscilloscope): 3 div/s
