Nsk nakanishi high speed air jig grinder planet 850
Nsk Nakanishi High Speed Air Jig Grinder Planet 850
HIGH SPEED AIR JIG GRINDER PLANET 850 70,000~90,000 min-1(rpm)
Turns Milling Machine into Jig Grinding Machine, Lathe into Internal Grinding Machine.
Easily mounted on available boring head.
PLANET 850 : 70,000~ 90,000 min-1(rpm).
Planet 850 Jig Grinder Collet 1/8" (CHA-3.175) : 1 pc. Collet Nut (K-263) : 1 pc. Intake Air Hose (K-259) : 6 mm x 6 ft Anti-swivel Bar Wrench (10 x 10), (8 x 5) : 1 pc. each Filter Joint (FJ-01).
Motor Speed is 70,000~90,000 min-1(rpm)
Shank type is provided only straight.
Use with compact compressor (1.47 kw)
Best for the internal grinding of small diamete ( 0.08"~ 1.18")
Suitable for internal grinding jig borer, jig milling machine and lathe.
Collet : Standard size 1/8" (CHA-3.175).
Special size 0.5~ 4.0 mm (Optional).
Speed 70,000~90,000 min-1(rpm)
Air Consumption 5.30CFM (71PSI)
Hose Intake Air 6.0 mm (O.D.) 6 ft
Processable Diameter 0.08"~ 1.18"
Max. Grindstone Diameter 0.28" ( with 3.0 mm mounted wheel )
PLANET Series Features & Examples of Applications
Energy saving mechanism operated by a compact compressor {Min. 0.4 kw~Max. 3.7 kw (1/2HP~5HP)} with small air consumption.
The PLANET 550 System has adopted an exhaust air silencer system keeping noise to a minimum.
Excellent performance for relatively low cost.
Turns a milling machine, etc. into a jig grinding machine by simply attaching a boring head obtained in the market and PLANET Series.
If mounted on a lathe, this grinder can be used as a precision internal grinder.
Can be used for the high-speed rotating portions of various kinds of specialized machine. By changing the chucks, tools in the market can be used. Standard size chucks are 1.6 mm, 2.35 mm, 1/8", 1/4". Optional size chucks are also available.
Built-in special high speed ball bearing withstands long continuous operation.
Ultra-precision special ball bearing accomplished by many years of joint study between NAKANISHI and ball bearing manufacturers.
