71" tbl 15HP spdl hitachi #4 horizontal mill, #50 taper
71" Tbl 15HP Spdl Hitachi #4 HORIZONTAL MILL, #50 Taper
71" Table 15HP Spindle Hitachi #4 HORIZONTAL MILL, #50 Taper,2 Arbor Supports, Feeds & Rapids All Wa
HITACHI HORIZONTAL MILLING MACHINE
MODEL: 4M S/N: 713-50-8 NEW: 1971
TABLE SIZE ......................... 14" x 71"
TABLE LONG. TRAVEL ................. 41-1/4"
TABLE CROSS TRAVEL ................. 14"
VERTICAL KNEE TRAVEL ............... 19-1/4"
SPINDLE SPEED RANGE(16) ............ 25 - 1,500 RPM
SPINDLE HORSEPOWER ................. 15 HP
LONG. & CROSS TABLE FEEDS(16) ...... 21 - 85 IPM
VERTICAL FEED SETTINGS ARE HALF OF LONG & CROSS
DIMENSIONS ......................... 103" x 87" x 91"H
WEIGHT ............................. 10,500 lbs.
- RAPIDS & FEEDS ALL DIRECTIONS
- AUTOMATIC LUBRICATION SYSTEM
- 15 HORSE POWER MAIN SPINDLE MOTOR
