Powermatic m 90 12" wood lathe operating & parts manual
This is a reproduction, not a photocopy, of an original Powermatic Model 90 12" Wood Lathe Maintenance Instructions and Parts List Manual. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams. This manual has great instructions and diagrams on removing the spindle and for adjusting the belt and drive. I personally own this lathe and this is a great manual for anyone else who does.
Specifications...................................1
Lathe Speeds.....................................2
Installation.....................................2
Maintenance Instructions.........................3
Spindle Removal..................................4
Lubrication......................................5
Belt Drive Adjustment............................6
Tailstock Adjustment.............................7
Trouble-Shooting.................................8
Electrical.......................................9
Stand and Bed Assembly.....................10 & 11
Head Area Assembly.........................12 & 13
Face Plates.....................................14
Drive Area......................................15
Lathe Guard.....................................16
Outboard Turning Stand..........................17
Tool Rest.......................................18
