14" swg 40" cc birmingham ndl-1440 special package engi
14" Swg 40" cc Birmingham NDL-1440 Special Package ENGI
14" Swing 40" Centers Birmingham NDL-1440 Special Package ENGINE LATHE, 6 HP, 12 Speed, 2-1/16" Spin
Model: NDL-1440 w/Removable Gap Block
Note: the photo shows the 16" x 60" centers model
Attachment (including installation)
Hardened and ground gears and shafts
Oil bath lubricated headstock and gear box for smooth, quite operation
12 spindle speeds, 32 - 2,000 RPM
Full length splash guard and foot brake
Wide range of feed and thread selections
Fully enclosed quick-change gear box
Large diameter leadscrew and feed rod
Equipped with chuck guard and tool post guard
Swing over cross slide: 7-1/4"
Spindle nose type (Camlock): D1-6
Spindle speed range: 32 - 2,000 RPM
Spindle center to bedway: 7-1/8"
Threads per inch (No.) range (TPI): (44) 2 - 56
Metric threads (No.) range (mm): (24) 0.5 - 14
Module threads (No.) range (mm): (24) 2 - 56
Diametral threads (No.) range (DP): (44) 0.5 - 14
Long. feeds (No.) range (in/rev): (18) 0.002 - 0.032
Cross feeds (No.) range (in/rev): (17) 0.0007 - 0.0095
Leadscrew diameter (in): 1-3/8"
Main drive: 6 hp, 2-Speed, 220V 3 ph Only
Maximum workpiece weight: 900 lbs.
Overall Dimensions: 90" L x 40" W x 48" H
8" 3 Jaw Chuck with top reversible jaws
Steady rest capacity 1-1/2" - 4"
Follow rest capacity 3-1/4" - 1-3/8"
12" Capacity steady rest with roller jaws
5C Hand lever type collet closer "JFK" (USA)
DRO - Newall, Acu-Rite or Uniq
Unisorb (USA) LR-2500 Leveling Pads
