2000 gal northland reactor, 304 s/s, 75/150#
2000_GAL_NORTHLAND_REACTOR,_304_S~S,_75~150-num-
2000 GAL NORTHLAND REACTOR, 304 S/S, 75/150#
One (1) used 2000 gallon Northland reactor, 304 stainless steel construction, 6' 5" diameter x 7' 3" straight side, dish top and bottom, rated 75 psi and full vacuum at 365 f, jacketed on bottom and 6' up straight side for 150 psi at 365 f, 20 hp ProQuip agitator drive, model 20YHS20 with mechanical seal, 230/460 volt xp motor, two tier 4 blade pitched turbine blade, 4 baffles, 18" manway, (2)5" sight glass, 10", 3", (3)2" top nozzels, 3" center bottom outlet on 4 legs, serial# 94-6683, national board# 1860, new 1995.
