Pc usb portable 5 channel automotive oscilloscope
PC USB Portable 5 Channel Automotive Oscilloscope
View signal voltages wherever you are with this easily portable 5 channel oscilloscope which plugs into your PC s USB port making this an ideal unit for both field and lab work.
Series communication test,for example 232
Sensor tester,for example temerature and humidity meter sensor, wind speed sensor, light sensitive sensor,vibration sensor, human body infrared sensor,microwave movement monitor sensor, human body pulse sensor and so on.
SCM three-phase electric, frequency, voltage parameters analysis, electric generater monitor.
Use with electronic teaching equipment
Examine and repair apparatus and appliances
Used in lab and industrial process monitor systerm
The portable oscilloscope is easily potable and takes its power directly from the USB port no batteries or other external power supply is required.
5 channel input and synchronised display
Measure range automatically with 4 available modes
Input capture (trigger) function
Any channel may be set as the source of capture (trigger) signal
Either rising or falling edge can be set to capture (trigger) signal
Adjustable capture (trigger) signal level
Saves data on hard disk and system will automatically summon data when started
BNC connection with universal oscillograph probe
Horizontal 16DIV * vertical 10DIV
800MV, 8V when probe is X10
Vertical baseline adjustable range
