Jig & fixture design milling drilling tooling templates
VOLUME ONE - TOOL DESIGN SERIES
This is a very good 1947 Jig design book from Bell Areosystems. It is in very good condition with a tight binding, solid spine, very good cover & clean unmarked interior. This book is designed for those with a reasonable amount of skill in mechanical drawing and an understanding of machine tools and processes. 330 pages.
1. Introduction to Tool Design
4. How Designs of Jigs and fixtures are Planned
6. Description of the Units of Instruction
Simple Drill Templates - Procedures in Design, Drill Template - Simple Angle Plate Milling Fixture - Procedures in Design, Milling fixture
Plate type Drill Jigs with Clamping Screws - Drill Jig
Milling Machine Vise Jaws - Vise Jaws
Plate Type Drill Jigs with Clamps and Legs
Straddle Milling Fixtures - Channel Type Drill Jigs - Angle Plate Tapping Fixtures
Vise-Held Milling Fixtures - Combination Drill and Assembly Jigs
Volume 1 Supplementary Section
Suggestions for tool designer -Steels common to tool construction - Heat treatment of steels in tool construction - Drill jig bushings - Component parts of jigs and fixtures - Tolerances and allowances
