Digital rcd capacitance meter test muitimeter lcd 0.1PF
DIGITAL RCD CAPACITANCE METER TEST MUITIMETER LCD 0.1PF
6013L type digital capacitance meter is pocket, convenient operation, accurate numerical reading,
low-consumption, driven by battery, and showing numbers in a big LCD. Being accurate in measuring, it covers 9 measuring sections, a wide rang from 0.1 pF to 20,000 uF. It can be used in testing error testing, numerical analysis, selecting capacitance, measuring unknown capacitance, matching capacitance, and measuring the capacitance of cable, switch and printing electro circuit.
It is applied with CMOS double-bevel A/D convertor that is automatic in zeroing and polar selection, and makes instruction for beyond measuring range.
Wide measuring range, covering 9 measuring sections from 0.1pF to 20,000 uF that includes nominal value of any capacitance.
Biggest display value: 1999(3 1/2).
Zeroing: There is a zeroing knob on the front, easy for operation.
Data hold: Put the DH switch to "ON" and the DH sign will appear on the display.
Press "back light" button, the back light will light.
Temperature for accurate measuring: 25 degree C +/- 5 degree C.
Temperature range: working temperature: 0 degree to 40 degree; Storage temperature: -10 degree to 50 degree;
Power: a 9V laminated battery.
Rang Accuracy Definition Testing Frequency
200pF +/-0.5% of rdg +/- 20 digits 0.1pF 800Hz
2nF +/-0.5% of rdg +/- 20 digits 1pF 800Hz
20nF +/-0.5% of rdg +/- 20 digits 10pF 800Hz
200nF +/-0.5% of rdg +/- 20 digits 0.1nF 800Hz
2uF +/-0.5% of rdg +/- 20 digits 1nF 800Hz
20uF +/-0.5% of rdg +/- 20 digits 10nF 80Hz
200uF +/-0.5% of rdg +/- 20 digits 0.1uF 8Hz
2000uF +/-0.5% of rdg +/- 20 digits 1uF 8Hz
20000uF +/-0.5% of rdg +/- 20 digits 10uF 8Hz
