SERVICE MANUAL, John Deere Model H Tractors
Here you have a Maintenance Handbook!
2nd Edition - Just Released - December 2009!!!
1. This a Service Guide - a Service Manual with tips, warnings and helpful hints - Making it an OUTSTANDING SERVICE MANUAL spanning over 100 pages - expands the initial edition. This publication contains dozens of illustrations made up of photographs, sketches and figures along with supporting narrative.
2. This guide comes to you with comb type binding so that the pages lay flat on the bench or table surface, and is a printed copy of an Outstanding John Deere Model H Service Manual.
3. This guide closely follows the organization of the John Deere Model "H" Restoration Guide, and has been prepared as a Companion Book. Some duplication of material found in the Restoration Guide is included here because not everyone will have both of these books on hand.
4. Seven Sections: (1) Condensed Service Data, (2) Basic Engine, (3) Engine Subsystems [Cooling system, Governor, Clutch system, Carburetor and Electrical systems], (4) Transmission and Final Drive, (5) Front End/Steering Systems, (6) Hydraulic Systems, and (7) Oiling Diagrams. At the end of each major section is found a summary of all specifications that apply to that section - this for quick reference.
5. The text includes guidance gleaned from Field Service Bulletins, earlier versions of Deere & Co. Instruction & Part List (IPL) or DIR documents (DIRs 214, 248 and 276), Repair Catalog 59-R, current existing consolidated shop service manuals, and many basic observations simply not reflected in literature currently available, but were observed and learned "along the way".
6. Approximately four dozen TIPs and NOTEs guide and assist you along the way - these are in addition to simple statements of specifications and criteria. This document is written to be a Mechanic's Maintenance Handbook for the JD-H tractor.
7. Something learned "along the way" are the reasons why the PTO jumps out of gear, test for those conditions, and then remedies. These data are not found anywhere else!
Also available on CD & in color where appropriate for less! Send me a Note or call (***)-627-0430 for details.
