250 ft alpha fit-221 3/4" heat shrink tubing roll black
250 ft Alpha FIT-221 3/4" Heat Shrink Tubing Roll Black
This is a 250 ft Roll of Alpha Wire Co. 3/4" Heat Shrink Tubing, part number FIT 221 3/4. It is in new, never used condition.
FIT heat-shrink tubing offers a reliable way to protect and seal terminations or add additional
mechanical ruggedness. FIT preferred heat shrink products are made from premium compounds
under the tightest manufacturing controls. This means FIT will consistently have excellent physical
characteristics such as low longitudinal shrinkage and wide temperature ranges while providing an
elegant appearance when used alone or on OEM equipment.
* Tubing Type: Heat Shrinkable Tubing
* Tubing Material: Cross Linked Polyolefin
* Minimum Supplied ID(In): 0.750
* Maximum Recovered ID (In): 0.375
* Nominal Recovered Wall Thickness(In): 0.030
* Temperature Range: -55 to 135degrees C
* Shrink Ratio: Approximately 2:1
* Full Recovery Temperature: 121 degrees C
* Minimum Shrink Temperature: 90 degrees C
* Tensile Strength: 1500psi, Min ASTM D638
* Elongation: 200%, Min ASTM D638
* Low Temperature Flex(-55 degrees C) no cracking AMS-DTL-23053
* Heat Shock(250°C,4hrs) no cracking AMS-DTL-23053
* Secant Modulus: 2.5x10 4 psi, Min ASTM D882
* Longitudinal Change: +/-5% AMS-DTL-23053
* Specific Gravity: 1.35, Max ASTM D792
* Shelf Life: 5 Years @ 0 to 35 degrees C
* Dielectric Strength: 500 V/mil, Min ASTM D876
* Volume Resistivity: 1x10 14 ohm-cm, Min ASTM D876
* Water Absorption: 0.50%, Max ASTM D570
* Fluid Resistance(23 degrees C,24 Hrs): 1000 PSI, Min AMS-DTL-23053
* Vacuum Outgassing - CVCM: 0.89%, Max ASTM E595
* Vacuum Outgassing - TML: 0.16%, Max ASTM E595
* Vacuum Outgassing - TML(Clear) 0.09%, Max
