Automax pocket reference industrial controls reliance
This document is designed to serve as a quick reference for AutoMax system's. It includes information about programming, hardware module port and register descriptions, and a list of status and error codes. This document does not take the place of instruction manuals that describe the individual hardware modules, the programming languages, and the Automax Executive software.
SECTION I; STATUS AND ERROR CODES
* GENERAL TROUBLESHOOTING PROCEDURES
* ERROR CODE LISTING (BY LOCATION OF CODE DISPLAY)
* 57C417, 57C414, 57C418, 57C428
* .LOG FILES AND SCREEN DISPLAY
SECTION II; HARDWARE MODULE REFERENCE
* 45C33, 57C330 REMOTE MODULE REFERENCE
* 57C402 24-115 VAC / DC OUTPUT
* 57C403, 61C503 115 VAC OUTPUT
* 57C404 NETWORK COMMUNICATIONS
* 57406,57405 DRIVE CONTROL AND ANALOG I/O
* 57C409 2-CHANNEL ANALOG INPUT
* 57C418 ALLEN BRADLEY INTERFACE
* 57C424 MAXPAK III HIGH SPEED LINK
* 57C428 TOLEDO SCALE INTERFACE
* 57C429 AUTOMAX R-NET PROCESSOR
* 57C430, 57C431, 57C435 AUTOMAX PROCESSOR
* 57C491, 57C493 POWER SUPPLY
* 61C22. 61C023 LOCAL I/O HEAD
* 61C345 4- INPUT ANALOG RAIL (4-20 MA)
* 61C346 4 INPUT ANALOG RAIL (O - 10V)
* 61C350 2 IN / 2 OUT ANALOG RAIL (4-20MA)
* 61C351 2 IN / 2 OUT ANALOG RAIL (4 - 20MA)
* 61C365 4 OUTPUT ANALOG RAIL ( 4 - 20 MA
* 61C366 4 OUTPUT ANALOG RAIL (0-10V)
* 61C605 8 CHANNEL THERMOCOUPLE
* 61C613 16 CHANNELANALOG INPUT
SECTION III; PROGRAMMING REFERENCE
* BASIC LANGUAGE QUICK REFERENCE
* CONTROL BLOCK LANGUAGE QUICK REFERENCE
* CONTROL BLOCK EXECUTION TIME ESTIMATES
* AUTOMAX OFF LINE PC EDITOR QUICK REFERENCE
* PC/LADDER LOGIC EXECUTION TIME AND MEMORY USAGE ESTIMATES
* NORTON EDITOR COMMAND SUMMARY
* SUMMARY OF COMMON DOS COMMANDS
