Coolant pump for victor 1640G & takang 1740K lathes
Coolant Pump for VICTOR 1640G & TAKANG 1740K lathes6" shaft length. Suitable for many brands of lathes
Cast Iron Centrifugal Pump for Coolant Tank
This in-tank coolant pump is suitable replacement for many coolant pumps used on lathes, milling machines, grinders and other machinery.
Picture below shows the hole pattern on the mounting plate. A quick comparison with your coolant pump would determine if it'll fit.
Coolant output connection is NPT female 3/8" pipe size.
Shaft length (the section immersed in coolant tank) is 6".
Can be wired for either 220 or 440V, 3phase.
Out the factory, it's wired for 220V. Can be wired to 440 by placing a jumper at the wiring terminal. The motor plate has details.
Pressure: 7.11 psi (0.5 kg/cm^2)
If you have any questions regarding this item, please let me know I'll be happy to help. You can also reach us at Eisen Machinery toll free (***)-626-7285.
