New TES1333 tes-1333 solar power radiation meter tes
TES TES1333 Solar Power Radiation meter
Sourcing the best efficiency of Solar Energy Reception
W/m2 and Btu / (ft2 x h) units display
Current time setting function
Excellent long term stability.
Automatic transmission measurements.
Select either power or transmission.
Current time setting function.
User calibration factor setting function.
Select either W/m2 or Btu / (ft2 x h) units.
Data Hold/MAX/MIN/AVG modes.
Auto Data Memory and RS232 interface to PC. (TES - 1333R)
Physics ans optical laboratories
Solar transmission measurement
Identify high performance windows
3-1/2 digits. Max. indication 1999
Typically within 10W/m2 [ 3 Btu / (ft2 x h)] or 5%, whichever is greater in sunlight; Additional temperature induced error 0.38 W/m2/ C [ 0.12 Btu / (ft2 x h)/ C] from 25 C
Cosine corrected <5% for angles < 60
0 C to 50 C (32 F to 122 F) below 80%RH
Carrying Case, Operation Manual, 4 pcs size AAA, RS232 cable (for TES-1333R), CD software (for TES-1333R)
- TES T1333 Solor Power meter x 1
