Xb-2008C digital lcd display clamp multimeter temp test
The XB-2008C digital clamp multimeter has been manufactured and tested in accordance with IEC10101 Part 1 (Safety requirement for Electrical Equipment for measurement, control and laboratory use. Safety class II, Overvoltage category II).
- Clamp opens up to 1 inch (25.4 mm)
- Large 3 1/2 digit LCD display
- DC & AC Voltage, DC & AC Current, Diode (hFE) and Temperature measurement
- AC/DC Voltage measurement up to 600 Volt
- AC/DC current measurement up to 500A/200mA
- 3 readings per second sampling
- Automatic polarity indication
- Battery discharge indication
- Soft carrying deluxe pouch, test leads, thermocouple, operation manual and batteries included
- Large LCD display size: 1/2"
- Power: 2x 1.5V AAA size batteries (included)
- Test probes: One red and one black, 1000V/15A rated (IEC1010/EN61010 CAT II), 1 3/4' long
- Dimension: 7" (L) x 1 3/4" (W) x 1 3/16" (D)
- Weight: 5.76 oz. (including battery)
- For use in Electronic and electrical circuits, Automobiles, Trucks, Trailers, Boats, RVs etc...
- Measure currents in circuits like battery chargers, alternators, leakage currents, electrical loads, etc...
- Check grounds, Voltage drops and continuity across Connectors, Wires, Cables, Relays Contacts, Lamps, Switches, etc...
- An essential tool for all around troubleshooting of electrical and electronic circuit and systems.
Overload Protection: 700Vrms or 1000Vp
Response: Average, calibrated in rms of sine wave
Overload Protection: F200mA / 250V fuse
Overload Protection: F200mA / 250V fuse for 200 A ~ 200mA ranges
NOTE: 2A ~ 500A Ranges Test must use clamp
Overload Protection: 250V DC or rms AC
