Zhonghuan oxy-gasoline cutting torch/zh-C30T-en w/3TIPS
ZHONGHUAN Oxy-Gasoline Cutting Torch/ZH-C30T-EN w/3Tips
ZHONGHUAN Oxy-gasoline cutting torch outfit ZH-C10...
ZHONGHUAN Oxy-gasoline cutting torch outfit ZH-C30...
ZHONGHUAN Oxy-Gasoline CNC Cutting Torch Outfit/ZH...
ZHONGHUAN brand no-press oxy-gasoline cutting torch
SAVES Money, EASIER to use, and Works FASTER
A ZH-C30T-EN cutting torch with 3 cutting nozzles, C30N-1#,2#,3# cutting thick range 3-30mm(approx. 1/10-1 1/4 inches) steel.(Standard)
"ZHONGHUAN" brand QG4 type oxy-gasoline cutting fit is use the oxygen and gasoline through the cutting torch to mix, and fully combustion flame to form the high temperature to do gas cutting work
The cutting thick range 3-30mm(approx. 1/10-1 1/4 inches) standard
The Oxy-Gasoline Cutting Nozzle s Performance Parameter List
1. It is safer than acetylene and the other gas. Non-tempering, non-detonating. The fuel tank adopts the advanced explosion-proof device so that it can reduce the explosion probability to 0. It is impossible to explore even if the fuel tank contacts with the high temperature and open fire or to weld up the damaged fuel tank with gasoline. The cutting torch adopts several unique technology of ZhongHuan . When the oil tank is in the circumstances of non-pressure, the cutting torch can keep on burning but not tempering when it is in water.
2. Pollution-free, noiseless, no hurt to the operator.
3. No need of electricity and pressure, convenient to operate, no residual oil.
4. Smooth cut, no scarred, little slogging scarification under the cut.
5. Small volume, light weight, easy to carry.
6. Good economic return. 0.4~0.6L/h oil consumption when cutting the steel plate under 40mm. The cutting time of 6KL petrol is the same as two current standard tanks of acetylene.
7. This product can cut any steels that oxygen-acetylene flame could cut.
Our company has developed series of products: there are hand-holding types heating torch. Semi-automatic cutter bar and so on.
This series of products are especially recommended by the china welding society.
International EMS air freight mail service from China
Which is cheapest and safety and fast and 40% discount. It is about 7-15 days to reach.
To insure your local sender can exactly send your ordered items to your doorstep in time, please provide your telephone number to me when you pay for. This is very important.
Item must be return with : 7 days
Refund will be given as : Exchange
HARBIN ZHONGHUANKE ENVIRONMENTAL PROTECTION & ENERGY SAVING EQUIPMENT LT., CO, is the earliest entity enterprise in China to research, develop and production gasoline cutting. Until now, it has 12 years history of manufacturing oxy-gasoline cutting machine. ZHONGHUAN gasoline cutting technique is the only enterprise who gained the special recommendation from Chinese Welding Society. ZHONGHUAN gasoline cutting technique received the silver award at the 15th China Invention Exhibition. This was listed as national-level major new products by Department of Science and Technology and Ministry of Foreign Trade and Economic Cooperation, National Administration of Taxation, General Administration of Quality Supervision of China, National Environmental Protection Administration. The portable fire rescue oxy-gasoline cutting machine and the portable railway repair oxy-gasoline cutting machine were classified as special tools by Ministry of Public Security and Ministry of Railways. ZHONGHUAN has the great reputation in this field, and it is still doing OEM for many well-know brand oxy-gasoline cutting machine of the export goods.
ZHONGHUAN has a number of self-owned intellectual properties, and completely solved the bottleneck problem of the gasoline cutting technique. Also the manufacturing technique already identified by its stabilization and durability. The core technique of ZHONGHUAN gasoline cutting is in the lead of international field, and leads the development direction and trend of the gasoline cutting technique.
Sole supper injection system No pressure need to be add, it can freely use at the height of 6 meters and can cut at complete circle all-directional. This is currently unmatched by similar products! Fuel control precision, gasoline and oxygen are synchronization.
Exclusive fuel control and regulator system Adapt gasoline-oxygen separation technique, safe and no flashback in the use! The anti-misoperation system let ignition and flame adjusting be ease, conveniences, reliable. All these cannot be achieved by similar products currently.
The history of ZHONGHUAN oxy-gasoline cutting
The main founder of the company combined with China Environmental Science Research Institute, established the oxy-gasoline cutting research project. More than 10 scientists had worked together for seven years, first gained Chinese national patents of the gasoline cutting technique of the balanced pressure torch by self-heating vaporization in 1998, and established HARBIN ZHONGHUANKE ENVIRONMENTAL PROTECTION & ENERGY SAVING EQUIPMENT LT., CO. (Hereinafter called the ZHONGHUAN ) in 1999. Its technology is a world leader at that time.
ZHONGHUAN continued to collect the information of the actual use, according to some complex and special requirements of working conditions, R & D Group developed fuel control and regulator system in 2000. Solved the internal pressure problem of the cutting torch, once again obtain a new national patent. The full range of cutting use, have laid a solid foundation to completely replace the acetylene gas cutting technology, the same year, passed the appraisal of scientific and technological achievements of the Science and Technology Committee, identified as high-tech achievements, and the technology is still the world's leading.
Under the influence of ZHONGHUAN in 2001, more people learned about the gasoline cutting technique and had gained tremendous economic benefits in use. As the technology advanced and a good use effect, ZHONGHUAN gasoline cutting products has been a sole focus recommended product in the industry by China Institute of Welding. ZHONGHUAN has become the industry's well-known brand in China.
There appeared no pressure gasoline cutting technique concepts in 2002. But because these products are rebuilt from acetylene cutting torch, so for the gasoline cut, injection power is low, fuel control instability, flame stability is poor. Actually, there are problems in use. ZHONGHUAN still insisted on the promotion of high-quality gasoline cutting products, and organizations research and develop that can really practical non-pressure gasoline cutting technique.
ZHONGHUAN R & D team according to the requirements of the domestic and international market, developed a high-strength injection (no pressure) gasoline cutting products, and gained a series of new national patents in the end of 2006. This series uses gasoline-oxygen separation technique, convenient adjustment, flame stability, no pressure, comfortable to use on height more than six meters, and can be dual-use under pressurized or non-pressure, and so that the no pressure gasoline cutting technique was from concept into the practical application.
ZHONGHUAN non-pressure gasoline cutting technique formal sells to the market in 2007 caused a huge sensation. ZHONGHUAN once again became the focus of attention in the field of this industry. Due to superior product performance and demand for the gasoline cutting products in the international markets, ZHONGHUAN production high quality gasoline cutting products for more well-known gasoline cutting brands to sell overseas.
ZHONGHUAN R & D group according to the operation habit of Chinese workers long-term use acetylene, developed ZHONGHUAN seventh-generation gasoline cutting products in 2008. This technique upgraded again on the high strength of injection system fuel control system, to make products more user-friendly to satisfy the workers using habits, and achieved exactly the same operating state as acetylene. And the oxygen consumption of 30-type cutting torch is less than the acetylene, The No. 0 cutting nozzle which is unique own by ZHONGHUAN can be used in cutting less than 3mm plate, saving fuel and oxygen in the no pressure state.
ZHONGHUAN R & D Group continued its user-friendly upgrade at the products in 2009. On the original product's superior performance, they added the anti-misoperating system again. Make the product easier to use, durable, and easier manipulation for users. ZHONGHUAN is still the controller of the core technology of the gasoline cutting and leading the development direction and technique trends of the gasoline cutting.
Welcome to contact us! Sincerely expect to cooperate with you.
