Preferred P3DC12-8-5 8 camera 12VDC 5AMP power supply
Preferred Power Products P3DC12-8-5 P3DC1285 P3 8 Camera 12VDC 5 Amp Power Supply
* Convenient screw terminal and fuse access.
* Separation panel between transformers and output access.
* Individual LED s for each fused output.
* Lockable heavy gauge metal enclosure.
* Double coated polyurethane finish.
* Multiple knockouts to accommodate various wiring configurations.
* Uses easy to find automotive style fuses.
The P3DC12-8-5 is a CCTV power center engineered to manage remote camera and accessory power requirements. The P3DC12-8-5 distribution module is designed with 8 individually fused outputs for powering up to 8 CCTV cameras and accessories.
It will provide 12 VDC via distribution to eight fused outputs with a total of 5 Amps continuous supply current. The P3DC12-8-5 power center is housed in the premium P3 lockable heavy gauge metal enclosure.
* Input 115VAC 50/60 HZ; 1.0 Amps.
* Eight 12VDC individually fused outputs.
* 5 Amps 100VA supply currents at 70 F.
* Output fuses are rated at 3 Amps.
* Main fuse is rated at 7.5 Amps.
* Transformer: 110/28VAC, 100VA.
* Enclosure dimensions: 10 (H) x 9 (W) x 4.5 (D).
