M & m gleason gear pitch diameter measurement system
M & M Gleason pitch diameter measurement systems-dimensions over pins gages, tested working, excellent condition.
Photographs are actual item forsale
http:// /metrol_overpins.html
Pitch Diameter Measurement Systems - Dimension Over Pins Gages
* Repeatable and reproducible results
* Affordable alternative for controlling component size
* Easy to operate - manual and motorized options
For use in the inspection lab or in the manufacturing cell, Gleason-M&M's semi-automatic and manual pitch diameter measurement systems provide reliable dimension over pins or balls measurements to verify actual tooth thickness (or space width) at the pitch diameter. A unique constant-pressure gaging system assures accuracy over the full range of the gage. Each system is equipped with a digital readout with data output port which can be linked to an SPC processor.
Setting masters are not required to setup external semi-automatic systems to measure components. Internal semi-automatic systems require only one certified, smooth ring for initial setup. Systems with a vertical lift table eliminate the need for platens to stage parts and allow the operator to check tapered or crowned components.
