New dormont countertop equipment gas connector kit 24"
The Countertop Gas Connector is the newest member of the Dormont Safety System . This product has been designed specifically to safely supply the required gas flow for efficient operation of cooking equipment at maximum capacity. The ability to provide sufficient gas flow is critical to the proper performance of the appliance. The Countertop Gas Connector is constructed using heavy-duty corrugated stainless steel tubing that is wrapped with stainless steel braid for reinforced flexibility. Additionally, the connector is coated in an antimicrobial PVC coating that inhibits the growth of bacteria, mold and mildew.
Reinforcing our commitment to Safety through Mobility Dormont s Countertop Gas Connector meets the ANSI Z21.69/CSA 6.16 standard. This standard requires the use of a movable grade gas connector on appliances that can be moved for cleaning or service. This connector was designed to specifically meet the typical movement requirements of countertop cooking equipment.
Countertop Gas Connector Advantage
These connectors allow foodservice kitchens to remain in compliance with the codes, while supplying countertop appliances with the required flow of gas to maintain maximum performance. Dormont gas connectors set the standard in the foodservice industry. The Dormont countertop gas connector is designed specifically for use with commercial cooking equipment. With over 75 million gas connectors installed worldwide, Dormont is the brand you can trust for your gas connection needs.
* Flexible corrugated stainless steel construction
* Tight weave stainless steel braid for reinforcement
* Smooth easy to clean antimicrobial PVC coating
For Natural Gas Connector Minimum flow capacity (per ANSI Z21.24/CSA 6.10 & ANSI Z21.75/CSA 6.27) Straight Length Capacity- BTU per hr 0.64 SG., 1000 BTU per Cu. FT. at 0.5 inch Water Column (124 pa) Pressure Drop
For Propane Gas Connector Minimum Flow Capacity (per ANSI Z21.24/CSA 6.10 & ANSI Z21.75/CSA 6.27)
Straight Length Capacity- BTU per Hr 1.55 SG., 2500 BTU per CU. FT. at 0.5 inch Water Column (124 Pa) Pressure Drop
24" Long x 1/2" Interior Diameter
Includes elbows and 1/2'' full port ball valve
Countertop Appliance Applications:
ANSI Z223.1 National Fuel Gas Code-National.Fire
Prevention Association N.F.P.A. #54
ANSI Z21.69/ CSA 6.16 Connectors for Moveable Appliances.
Pipe Connectors for Flammable and Combustible Liquids and LP-Gas.
For use with natural gas and propane.
National Sanitation Foundation Criteria C-2 special equipment.
City of New York MEA #98-83, 99-84, 100-83
Approved by the Commonwealth of Massachusetts Board of State
Examiners of Plumbers & Gas Fitters. (36'' maximum length)
CSA - B149.1 Natural Gas and Propane Installation
Description Part # I.D. 24'' 36''
Includes 1/2'' F x F elbow and 1/2'' F x 3/4'' F reducing elbow CT1650 1/2'' $59.00 $68.00
Includes elbows and 1/2'' full port ball valve CT1650KIT 1/2'' $ 66.00 $74.00
#CT1650KIT-24 COUNTER TOP GAS EQUIPMENT HOSE CONNECTOR KIT
