Dayton high volume direct drive duct vent blower
Dayton High Volume Direct Drive Duct Vent Blower
Dayton Single Inlet Forward Curve High Volume Direct Drive Blower
Single-Inlet Forward Curve Direct-Drive Blowers
Provide high-volume ventilation when duct systems are required.
Housing can be adapted to any of 8 discharge directions. Feature dynamically balanced wheels. Motor packed separately when ordered with blower.
Max. inlet air temp.: 180 DegreeF
Max. ambient temp.: 104 DegreeF
Great for medium pressures; combine characteristics of high-volume and high-pressure blowers.
16-ga. steel housing with welded, airtight joints. Heavy steel wheel. Blower drive package consists of appropriate motor to obtain performance listed. All motors are 60 Hz, rigid mounted.
Single Inlet Forward Curve Direct Drive Duct Blower, Wheel Diameter 9 Inches, Wheel Width 4 1/2 Inches, Bore Size 7/8 Inch, Inlet Diameter 9 Inches, Outlet Height 10 3/4 Inches, Outlet Width 6 1/2 Inches, Overall Height 18 Inches, Overall Width 16 Inches, Overall Depth 15 Inches, Without Motor
ItemBlowerTypeHigh Volume Direct Drive Forward Curve Less MotorWheel Dia. (In.)9Max. Inlet Temp. (Deg. F)180Max. Ambient Temp. (F)104Height (In.)18Width (In.)16Depth (In.)15Inlet Dia. (In.)9Outlet Height (In.)10-3/4Outlet Width (In.)6-1/2Wheel Width (In.)4-1/2Wheel Bore (In.)7/8Wheel MaterialSteelRotationCW Viewing Drive SideHousing MaterialSteelHousing FinishGray Polyester Epoxy
