National instruments ni pci-7030/6040E daq board
National Instruments NI PCI-7030/6040E DAQ Board
The National Instruments PCI-7030/6040E board is one of the RT Series hardware. The RT Series family of boards are multifunction I/O boards with an embedded processor. LabVIEW RT and NI-DAQ create embedded, real-time applications that execute on the RT Series board. The RT Series board, along with LabVIEW RT and NI-DAQ, provide an easy to use system for real-time applications. Each RT Series board is made up of two parts a processor board and an DAQ daughter board. The processor board contains an embedded microprocessor that runs real-time, embedded LabVIEW RT applications. The DAQ board provides the same high-performance DAQ as National Instruments non-RT DAQ boards. For example, the PXI-7030/6040E contains an DAQ board that is equivalent to the PXI-6040E.
* Integrated real-time measurement and control for PCI and PXI
* Dedicated onboard processor
* Fully programmable with the LabVIEW Real-Time Module
* Deterministic communication with the host PC
* 1 kHz single PID loop rates, maximum
