New 1.5 hp multi-speed tabletop drilling machine 3179
Speedway Series Drilling Machine 03179
Variable Speed / Auto-Feed Drilling Machine
* Ground Cast Iron Construction
* Spindle speed range: 300 - 1600 RPM Variable
* Motor: 1.5HP, 110 Volt, Single Phase/60Hz, 1720RPM, Capacitor start induction
* Maximum distance from chuck to table: 22" Chuck to base: 40.5" Column to chuck ctr.: 9.25"
* Maximum spindle travel: 3.5", Spindle taper MT3, Chuck cap. .625"
* Height: 68-1/2" Width 18" Overall Depth 30" Base Size 18" x 25" Quill Dia. 2.050"
* Dimension of worktable surface: 12" x 13"
