Rigol DS1302CA 300MHZ digital oscilloscope dso 2GSA/s
RIGOL DS1302CA 300Mhz Digital Oscilloscope 2 GSa/s Single Channel
Product Dimensions: Weight: 2.3 kg
2 GSa/s(Single Channel), 1 GSa/s(Dual Channels)
Advanced Features 1. The 2 GSa/s maximum real-time sample rate,the 50 GSa/s maximum equivalent time sample rate and up to 300 MHz of bandwidth ensures you capture and observe your entire signal
2. Up to 2000 wfms/s refresh rate
3. Ultra Compact Design with small footprint save your bench space
4. 5.7 64K TFT color LCD, bright and vivid waveform display
5. Memory depth: 10 kpts (Single Channel),
6. Versatile trigger modes: Edge, Video, Pulse Width,
7. Adjustable trigger sensitivity: Effectively filter noise fromtrigger signal and avoid false trigger
9. Cursor measurements: Manual, Track and Auto Measuremodes
13. Built-in hardware frequency counters
14. Dual channels plus external trigger. Bandwidth including60 MHz, 100 MHz, 200 MHz, 300 MHz
15. Standard interface: USB Device, RS-232 USB Host, to
support USB disk and USB printer
16. Standard configuration: Pass/Fail test,the signal out ofthe pass fail function is isolated to prevent unwantedinterference
17. Multi-language user interface, built-in help system
The DS1000CA series can be directly connected with the Rigol DG series function/arbitrary waveform generators. When connected with the built-in USB port of DS1000CA, the DG series function/arbitrary waveform can regenerate waveforms by visiting waveform memories of the latter's.
