24V dc, 2.1A switching power supply, desktop, nos
INPUT VOLTAGE: 90Vac TO 264Vac
INPUT CURRENT: <1.6A rms AT 90VAC INPUT
OUTPUT VOLTAGE: 24VDC, NO LOAD TO FULL LOAD, NO MINIMUM LOAD REQUIRED
RATED OUTPUT POWER: 50 WATTS, MAXIMUM
OUTPUT REGULATION: +/- 5% MEASURED AT THE OUTPUT CONNECTOR
LINE VOLTAGE REGULATION: +/- 1% TYPICAL MEASURED AT FULL LOAD
HIGH FREQ. OUTPUT RIPPLE: 1% OF OUTPUT VOLTAGE , PEAK TO PEAK, TYPICAL
TURN-ON/TURN-OFF OVERSHOOT: 5% MAXIMUM, 1mS TYPICAL RECOVERY TIME FOR 25% STEP LOAD
TURN-ON DELAY: 1 SECOND, TYPICAL
HOLD-UP TIME: 10mS TYPICAL AT NOMINAL INPUT VOLTAGE AND FULL LOAD
INRUSH CURRENT: 20A TYPICAL AT 115Vac INPUT AND 30A TYPICAL AT 230Vac INPUT
SWITCHING FREQUENCY: 100KHZ TYPICAL
EFFICIENCY: 75% TYPICAL AT NOMINAL INPUT AND FULL LOAD
OUTPUT INDICATOR: GREEN LED FOR OUTPUT PRESENT
OVER-VOLTAGE: VOLTAGE LIMITED BY CROWBAR METHOD
OVERLOAD: HICCUP MODE WITH AUTO-RECOVERY (110 - 130% OF RATED LOAD)
SHORT CIRCUIT: HICCUP MODE, OUTPUT WILL AUTORECOVER UPON REMOVAL OF SHORT
INPUT PROTECTION: INPUT LINE FUSING
DIELECTRIC WITHSTAND VOLTAGE: 4242Vdc FROM PRIMARY TO SECONDARY
EARTH LEAKAGE CURRENT: 500uA at 264Vac INPUT VOLTAGE
ITE UNITS: UL 60950 (THIRD EDITION), CUL TO 22.2 NO. 60950, TUV TO EN60950,
PSE TO J60950, CB REPORT, AS/NZ 60950, CCC TO GB4943-2001,GB9254-1998,
EMI: COMPLIES WITH EN55022 CLASS B AND FCC PART 15 CLASS B, VCCI
WHEN TESTED WITH RESITIVE LOAD, BOTH CONDUCTED AND RADIATED EMI.
CE MARK: TESTED TO COMPLY WITH EN61000-3-2 EN610003-3 AND EN50082-1
INCLUDING EN61000-4-2 (SYSTEM LEVEL), EN61000-4-3, EN61000-4-4,
EN61000-4-5, EN61000-4-6, EN61000-4-11 LEVEL 4.
C-TICK TESTED TO COMPLY WITH AUSTRALIA SECTION 182 OF THE RADIO COMMUNICATION
MTBF: GREATER THAN 50,000 HOURS AT 25 C AMBIENT TEMPERATURE
NOMINAL LINE AND FULL LOAD (MIL-217 STD)
OPERATING TEMPERATURE: 0 C TO 40 C AMBIENT TEMPERATURE
STORAGE TEMPERATURE: - 40 C TO 80 C
Output Plug: 3 MALE MINI DIN KYCON KPP-3P LOCKING OR EQUIVALENT
Large quantity available upon request.
GS-567 SWITCHING,POWER Ea 3 0.00000 0.00 3
SUPPLY,50WATT,24VDC@2.1ADESKTO
