De-sta-co 82G6S231C9031031180B pneumatic clamp
DE-STA-CO DeStaCo 82M-7D63 OVAL PNEUMATIC CLAMP
DeStaCo 82M-7D63 Oval Power Clamp
Holding Force: 737 ft-lbs (1000Nm)
Clamping Force at 75psi (5 bar): 309 ft-lbs (420Nm)
Max. Operating Pressure: 100psi (7 bar)
Arm Position Tolerance: +/- 0.33
Arm Lateral Tolerance: +/- 0.3mm
Cylinder Bore: 2.48 in. (63mm)
Air Consumption per Minute at 85psi (6 bar): 0.13 ft3 (3.8 liters)
Opening Angle: 15 - 120 (In 15 Increments)
Port Options: 1/4 NPT and 1/4G, 180 apart on every cylinder
Mean Time Between Failure (MTBF): 3.25 Million Cycles
Mean Time to Repair (MTTR): 30 Minutes
The 82M Oval Power Clamp is ruggedly designed and built to perform repetitive production operations yet portable enough to use on end effectors and light-duty fixturing.
* Easily field-adjustable angle-of-opening modifications in 15 increments
* Gasket-sealed proximity switch cartridge
* Toggle-lock release button
* NAAMS-Style Arms and Mounting Patterns
