Logan 11" lathe #1922 manual, parts list
11-inch Logan Lathe Parts List
This is a reproduction, not a photocopy, of an original Logan 11-inch Lathe Parts List. This manual contains complete parts list and exploded views of the lathe. This is a very good manual that covers everything stated below in the contents.
Shifter Rack Assembly..............................................2
Gear Guard Assembly..............................................3
Reverse Gear Assembly............................................4
Change Gear Assembly............................................5
Compound Rest Assembly.......................................6
Saddle Assembly......................................................7
Worm & Clutch Assembly.......................................8
Automatic Apron Assembly.....................................9
Gear Box Assembly...............................................10
Dial Indicator Assembly..........................................11
Tailstock Assembly.................................................12
Bed Assembly........................................................13
Drive Box Assembly...............................................14
Bench Stand & Guard Assembly.............................15
Legs, Pan, and Pedestal..........................................16
